Engine oils

HDAX® 5200 Low Ash Gas Engine Oils

15W-40, 30, 40

Engine oils

HDAX® 5200 Low Ash Gas Engine Oils

15W-40, 30, 40

HDAX® 5200 Low Ash Gas Engine Oils are advanced performance, premium quality, bright stock free, low ash, dispersant/detergent type engine oils.

Where to buy ›

PDS ›

SDS ›

Fast facts

Supported equipment types

Delivering value for you

HDAX 5200 Low Ash Gas Engine Oils deliver value through:

Low maintenance cost and long engine life

Low wear

Provide excellent protection against piston, ring, and liner scuffing, scoring, and wear.

Valve protection

The level and type of ash producing additives in the oils provide minimum valve recession with low levels of combustion chamber deposits to minimize the potential for preignition and spark plug fouling.

Clean pistons

Provides piston cleanliness to help prevent ring sticking and maintain clean, varnish-free piston skirts.

Clean crankcases and top decks

Minimizes the formation of crankcase and valve cover/top deck sludge.

Catalyst compatibility

Formulated to be compatible with exhaust emissions reduction systems.

Excellent low temperature performance

HDAX 5200 Low Ash Gas Engine Oil SAE 15W-40 provides maximum oil flow to engine components for better lubrication during cold startup, compared to straight grades.

Expand Collapse

Applications

HDAX 5200 Low Ash Gas Engine Oils are recommended for four-stroke and selected two-stroke stationary engines fueled by natural gas. HDAX 5200 Low Ash Gas Engine Oil SAE 40 is approved for:

• Caterpillar Energy Solutions GmbH for CG132,CG170 & CG260 gas engines

• GE Jenbacher Type 2, 3, and 4 (versions A & B) gas engines burning fuel class A (natural gas) ,including engines with oxidation catalytic converters. Type 4 (version C) gas engines burning fuel class A(natural gas), B (biogas) and C (landfill gas) ,including engines with oxidation catalytic converters.Type 6 (versions C & E) gas engines burning fuel class A (natural gas), including engines with oxidation catalytic converters. Type 6 (version F) gas engines burning fuel class A (natural gas), B(biogas) and C (landfill gas), including engines with oxidation catalytic converters

• MAN Diesel & Turbo engines in operation on natural gas (CNG/LNG) - now MAN Energy Solutions

• MAN Energy Solutions for use in MAN ES fourstroke medium speed engines on natural gas (CNG/LNG) - formerly MAN Diesel & Turbo

• MWM gas engines

• Wärtsilä gas engines and dual fuel engines with natural gas as main fuel

• All Waukesha gas engines burning pipeline quality gas

HDAX® 5200 Low Ash Gas Engine Oils are recommended for four-stroke gas-fueled engines manufactured by:

— Caterpillar

— Delaval Enterprise

— Dresser-Rand (Categories I, II, and III)

— MWM (DEUTZ)

— Superior

— Worthington

HDAX 5200 Low Ash Gas Engine Oils are formulated to meet catalyst compatibility requirements and are especially suited for installations requiring low phosphorus oil to prevent exhaust catalyst poisoning.

HDAX 5200 Low Ash Gas Engine Oils are suitable for use with fuels containing low levels of sulfur. In sour gas applications, a lubricant with higher base reserve
